Available with three lid options: round, square or snap-in round/square
Part # SKR1xx-OZ Includes All of The Following
- Junction Box with Round Lid - Part # JBRxxx
- Junction Box with Square Lid - Part # JBSxxx
- Bubbler Plate - Part # BPxxx
- Flush Mount Fitting - Part # 3xx
Features
- Adjustable collar
- New weir clip lock secures the clips in the weir door
- Weir plate with easy snap in and out locks
- Self-contained gunite grip, water stop on face plate to prevent water leaks
- Large self-contained basket with lock-in feature (will not float)
- Pre-installed O-ring for float assembly
- Underwater dampers on face plate for noise reduction on weir plate – especially on windy days
- Super strong engineered polymer upper housing
- Extra heavy duty PVC lower unit (no transitional glue required)
- 2-1/2" outside slip and 2" inside slip (outside skimmer)
- 2" threads for pressure testing (inside skimmer)
- Built-in overflow or fill line knock out
- Upper housing has pre-cut rebar cut outs with pre-drilled holes for tie wire
- Additional box inside skimmer box for basket, float assembly and weir plate (so assembly does not get lost on job site)
- Skimmer Lid and Collar G154 UV tested
- NSF 50 approved for commercial use, 25 GPM min, 55 GPM max – approved for residential use up to 100 GPM
- Optional custom name/logo engraved on lid (requires minimum 100 piece lid order)
